The GASR-3D 'Terrier' radar is the next generation of Ground & Air Surveillance Radars (GASR).

  • Staring radar
  • FMCW radar technology
  • Automatic detection
  • Automatic classification
  • Automatic tracking
  • LPI technology
  • High MTBF
  • Built-in GPS and magnetic compass
  • Withstand harsh environmental conditions
  • Interfaced via Ethernet 1G
  • Unique capability: Drone, UAV and Human Detection in same radar
  • DBF and unique Tx AESA technology
  • Advanced Operator software
  • No moving parts, fully solid state
  • Compact and light weight
  • Fully integration ready (C4i/EO)
  • Continous real time detection and tracking
  • Tested according to MIL-STD-810G
  • The Radar is capable to continuously detect Drone, UAV and Human targets. The Radar provides automatic detection, tracking and classification of the targets.

  • it is based on Frequency Modulated Continuous Wave (FMCW) technology enabling high MTBF. It utilizes unique AESA transmission. Low power and continuously changing frequency providing for Low Probability of detection and Interception (LPI).

  •  utilizes multiple frequency channels in a wide operating frequency range to enable eliminating potential environmental disturbances and interferences and to adapt to the operating environment. Embedded GPS and magnetic compass units are built-in for quick deployment and settings.

  • can be fixed or portable due to its low weight and provides easy installation in hardly accessible locations.

  • certified to withstand and operate in harsh environmental conditions and is suited for off-road vehicles transportation conditions.

  • fully solid state, advanced digital design, providing for very high MTBF.

  • designed for easy integration with Command and Control Systems and can be interfaced via Ethernet 1G.
